| BOURDON
TUBE PRESSURE GAUGE - 55.1111 |
| Stainless
Steel Manometer-Case 63 MM-Glycerin
Filled Brass Connection 1/4"
BSP/NPT Down |
|
| Accuracy
: |
2.5% |
| Scales
: |
in bar
and PSI (red color) |
| Working
Pressure : |
steady
3/4 scale value |
| |
fluctuating
2/3 full scale value |
| |
short
time full scale value |
| Bourdon
tube : |
bronze |
| Connection
: |
brass
1/4" BSP/NPT down |
| Window
: |
policarbonate |
| Case
material : |
stainless
steel |
| Case
fill : |
glycerin
99.5% |
| Working
Temperature : |
-20
C (-4 F) + 60 C (+140 F) |
| Applications
: |
for
measuring points with high dynamic
pressure, pulsations or vibrations.
Hydraulics and compressors. |
|
|
Part Number
|
Serie
|
Case Size
|
Pressure
|
|
mm
|
inch
|
bar
|
PSI
|
|
55.1111.007
|
0-7 bar
|
63
|
2.1/2 "
|
0-7 bar
|
0-100
|
|
55.1111.010
|
0-10 bar
|
63
|
2.1/2 "
|
0-10 bar
|
0-145
|
|
55.1111.016
|
0-16 bar
|
63
|
2.1/2 "
|
0-16 bar
|
0-230
|
|
55.1111.025
|
0-25 bar
|
63
|
2.1/2 "
|
0-25 bar
|
0-360
|
|
55.1111.040
|
0-40 bar
|
63
|
2.1/2 "
|
0-40 bar
|
0-580
|
|
55.1111.060
|
0-60 bar
|
63
|
2.1/2 "
|
0-60 bar
|
0-870
|
|
55.1111.100
|
0-100 bar
|
63
|
2.1/2 "
|
0-100 bar
|
0-1450
|
|
55.1111.250
|
0-250 bar
|
63
|
2.1/2 "
|
0-250 bar
|
0-3625
|
|
55.1111.400
|
0-400 bar
|
63
|
2.1/2 "
|
0-400 bar
|
0-5800
|
|
55.1111.500
|
0-500 bar
|
63
|
2.1/2 "
|
0-500 bar
|
0-7250
|
|
|
|
|
|
|
|
 |
|
